Video Tutorial: Making corrections with layout templates

In this video we make corrections to a layout by using the existing layout template that the system has created when the layout was assembled with the template layout wizard.

Video: Making corrections using layout templates

Click the icon to watch the video. Run time: 0:36 min.

PROCEDURAL STEPS

1. (Having a layout drawing opened) Apply a layout template to a sheet: on the Layout toolbar, click Apply Layout Template to New Sheet .
2. Click the Fill by counts option, and then set the number of rows to 3 and the number of columns to 2.
3. Set a horizontal X Gap of 10 mm between the rows in the layout.
